Plow mixer

Product Description
The plow blade mixer is a highly efficient and multi-functional equipment for mixing powders and granules. Its unique structure enables it to achieve uniform mixing quickly and adapt to the process requirements of high-viscosity materials and liquid addition. It is widely used in the mixing processes that require strong stirring and dispersion in industries such as chemical engineering and food.

Working Principle
The plough mixer is an efficient and versatile powder and particle mixing equipment, widely used in industries such as chemical and food where strong stirring and dispersion are required in the mixing process. The core working principle of this device lies in using the high-speed rotating plough to throw the materials radially along the inner wall of the cylinder, creating a strong convection circulation. At the same time, it can be equipped with high-speed flying knives to shear and disperse the material lumps. The combined action enables even highly viscous materials or processes that require the addition of liquids to achieve a highly uniform mixing effect within a short period of time.

Structural features
In terms of structural design, the plough mixer exhibits distinct functional characteristics. The U-shaped or trough-shaped cylinder is made of stainless steel with wear-resistant properties, and its inner wall is polished to reduce material adhesion. The top flange for feeding and the bottom butterfly valve for discharging achieve an automated process. The main shaft is equipped with multiple sets of wear-resistant plough blades, and the angles of the two sides' flying blades can be adjusted independently and driven separately. It is also paired with a high-strength alloy steel main shaft and a variable-frequency transmission system. Additionally, labyrinth seals or mechanical seals are combined with dust collection interfaces to effectively control dust leakage, meeting the clean production requirements of industries such as chemical and pharmaceuticals.

Product features
1. Efficient and uniform: Utilizing the powerful convection and shearing forces of the plow blade and the flying knife, it can quickly achieve high uniformity of mixing.
2. Wide adaptability: Particularly skilled at handling high-viscosity and paste-like materials, and can conveniently complete solid-liquid mixing.
3. No dead zones in mixing: The unique motion design ensures that the materials circulate in all directions, with no dead zones in the mixing process.
4. Quick and thorough discharge: The large opening bottom valve design enables rapid discharge with minimal residue.
5. Strong and durable: Compact structure, strong load-bearing capacity, stable and reliable operation.

Product Parameters

Production line schematic diagram

Configuration A: Continuous vacuum feeder suction feeding → mixing → silo

Configuration B: Ton bag hoisting feeding → mixing → straight ton bag packaging
